2021 L3HCTF Misc lambda WP

阅读量

开局一个pcap数据包，flag在哪全靠猜～

两天只做了一道题，不过还是挺有收获的。顺便纪念一下第一次在大型CTF比赛中拿到带血的flag～

第一部分的flag的获取非常简单，只需要打开数据包追踪tcp流，就可以看到。

image-20211118170805438

因为做到这里的时候还没有提示，开始在数据包内进行自由探索。感觉题目中的DNS数据包和ICMP数据包都有明显的构造痕迹，所以思路开始发散。走了不少的弯路。

image-20211118170947878

第一天下午的时候题目突然发了hint，题目提供了一个github地址 https://github.com/dreamstalker/rehlds，是一个游戏引擎，和flag3有关。

我们开始重新收束思路，根据题目描述，后两部分的flag应该还是跟这个游戏服务器有关。

继续查看数据包中http传输的数据。发现有传输一个flag.wad文件还有一个flag.bsp文件。

image-20211118172659030

image-20211118175646053

我们首先尝试解析那个wad文件，google一下可知，这两个都是游戏数据文件。bsp是游戏地图。

找到了一个在线https://www.coolutils.com/online/WAD-to-PNG，但是转成图片之后只得到了一张没太大用处的图片。

flag

bsp折腾了半天，也没找到一个可以打开的方式，所以…

那我们直接安装 CS 1.6！！

加载 flag.bsp 对应的地图，进入游戏可以看到 FLAG 的相关提示。通过穿墙，可以找到 flag 的 part2。(想哥tql！

image-20211118171840387

根据这里的提示，我们可以明确flag有三部分。

image-20211118171948803

进入游戏 flag 地图后，并没有 hint2 的提示，但是对比连接服务器之后的欢迎界面，我们大概可以明确flag3应该就在服务器和客户端通信的udp数据包中。

image-20211118181255899

但是查看udp流，这些数据明显经过了特殊的加密处理，我们没有办法直接获得通信的数据。

image-20211118181543515

根据题目给出的hint，游戏服务器很可能是采用了上面的github代码搭建的。那为了弄懂这些udp乱码，我们就只有去看代码一条路了。(喂，说好是道misc呢？！

因为我们要找的数据一定是从服务器发到客户端的，所以我们要去看服务器发包部分的代码。

最开始我们开的却是是服务器发包部分的代码，但后来才意识到，我们需要解包，其实我们直接看收包部分的代码就好了。

又经过一番摸索后，我们找到了关于服务器收包部分代码的入口——SV_ReadPacket函数。这里为了逻辑清晰，删去了一些对我们意义不大的代码。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
void SV_ReadPackets(void)
{
	while (NET_GetPacket(NS_SERVER))
	{

		for (int i = 0 ; i < g_psvs.maxclients; i++)
		{
			client_t *cl = &g_psvs.clients[i];
			if (!cl->connected && !cl->active && !cl->spawned)
			{
				continue;
			}

			if (NET_CompareAdr(net_from, cl->netchan.remote_address) != TRUE)
			{
				continue;
			}

			if (Netchan_Process(&cl->netchan))
			{
				if (g_psvs.maxclients == 1 || !cl->active || !cl->spawned || !cl->fully_connected)
				{
					cl->send_message = TRUE;
				}

				SV_ExecuteClientMessage(cl);
				gGlobalVariables.frametime = host_frametime;
			}

			if (Netchan_IncomingReady(&cl->netchan))
			{
				if (Netchan_CopyNormalFragments(&cl->netchan))
				{
					MSG_BeginReading();
					SV_ExecuteClientMessage(cl);
				}
				if (Netchan_CopyFileFragments(&cl->netchan))
				{
					host_client = cl;
					SV_ProcessFile(cl, cl->netchan.incomingfilename);
				}
			}
		}
	}
}

但是似乎看不懂… g_psvs、netchan都是些什么QAQ

让我们耐心一些，一点点抽丝剥茧。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
server_static_t g_psvs;
typedef struct server_static_s
{
	qboolean dll_initialized;
	struct client_s *clients;
	int maxclients;
	int maxclientslimit;
	int spawncount;
	int serverflags;
	server_log_t log;
	double next_cleartime;
	double next_sampletime;
	server_stats_t stats;
	qboolean isSecure;
} server_static_t;
// 从上面我们能大概看出这个结构体里维护了一些服务器的基本数据，记录了服务器支持的最大客户端数量，还有客户端的信息。

由client_t *cl = &g_psvs.clients[i];这句代码我们可以知道cl是一个连接服务器的客户端。

让我们再来看看client的结构体长什么样子吧。

1
2
3
4
5
6
7
8
9
10
11
12
typedef struct client_s
{
	qboolean active;
	qboolean spawned;
	qboolean fully_connected;
	qboolean connected;
	qboolean uploading;
	qboolean hasusrmsgs;
	qboolean has_force_unmodified;
	netchan_t netchan;
	...
} client_t;

netchan_t netchan;又是在client里面定义的另一个结构体。结构体真是一个比一个长啊，不过我们好像接近真相了。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
// Network Connection Channel
typedef struct netchan_s
{
	// NS_SERVER or NS_CLIENT, depending on channel.
	netsrc_t sock;

	// Address this channel is talking to.
	netadr_t remote_address;

	int player_slot;
	// For timeouts.  Time last message was received.
	float last_received;
	// Time when channel was connected.
	float connect_time;

	// Bandwidth choke
	// Bytes per second
	double rate;
	// If realtime > cleartime, free to send next packet
	double cleartime;

	// Sequencing variables
	//
	// Increasing count of sequence numbers
	int incoming_sequence;
	// # of last outgoing message that has been ack'd.
	int incoming_acknowledged;
	// Toggles T/F as reliable messages are received.
	int incoming_reliable_acknowledged;
	// single bit, maintained local
	int incoming_reliable_sequence;
	// Message we are sending to remote
	int outgoing_sequence;
	// Whether the message contains reliable payload, single bit
	int reliable_sequence;
	// Outgoing sequence number of last send that had reliable data
	int last_reliable_sequence;

	void *connection_status;
	int (*pfnNetchan_Blocksize)(void *);

	// Staging and holding areas
	sizebuf_t message;
	byte message_buf[MAX_MSGLEN];

	// Reliable message buffer. We keep adding to it until reliable is acknowledged. Then we clear it.
	int reliable_length;
	byte reliable_buf[MAX_MSGLEN];

	// Waiting list of buffered fragments to go onto queue. Multiple outgoing buffers can be queued in succession.
	fragbufwaiting_t *waitlist[MAX_STREAMS];

	// Is reliable waiting buf a fragment?
	int reliable_fragment[MAX_STREAMS];
	// Buffer id for each waiting fragment
	unsigned int reliable_fragid[MAX_STREAMS];

	// The current fragment being set
	fragbuf_t *fragbufs[MAX_STREAMS];
	// The total number of fragments in this stream
	int fragbufcount[MAX_STREAMS];

	// Position in outgoing buffer where frag data starts
	short int frag_startpos[MAX_STREAMS];
	// Length of frag data in the buffer
	short int frag_length[MAX_STREAMS];

	// Incoming fragments are stored here
	fragbuf_t *incomingbufs[MAX_STREAMS];
	// Set to true when incoming data is ready
	qboolean incomingready[MAX_STREAMS];

	// Only referenced by the FRAG_FILE_STREAM component
	// Name of file being downloaded
	char incomingfilename[MAX_PATH];

	void *tempbuffer;
	int tempbuffersize;

	// Incoming and outgoing flow metrics
	flow_t flow[MAX_FLOWS];
} netchan_t;

从上面的变量名还有注释中，我们可以看出，Netchan这个结构体主要是用来处理网络传输的数据的。

大致理解了这些变量的含义后，我们就可以尝试阅读后面关于数据包处理的代码。从上面的 我们可以看到Netchan_Process这个函数，结合我们对于Netchan结构体的判断，可以确认这个函数是比较重要的。 因为这个函数比较大，所以我们一段一段来看。（代码有删减）

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
int MSG_ReadLong(void)
{
	int c;
	if (msg_readcount + 4 <= net_message.cursize)
	{
		c = *(uint32 *)&net_message.data[msg_readcount];
		msg_readcount += 4;
	}
	else
	{
		msg_badread = 1;
		c = -1;
	}
	return c;
}

qboolean Netchan_Process(netchan_t *chan)
{
	int				i;
	unsigned int	sequence, sequence_ack;
	unsigned int	reliable_ack, reliable_message;
	unsigned int	fragid[MAX_STREAMS] = { 0, 0 };
	qboolean		frag_message[MAX_STREAMS] = { false, false };
	int				frag_offset[MAX_STREAMS] = { 0, 0 };
	int				frag_length[MAX_STREAMS] = { 0, 0 };
	qboolean		message_contains_fragments;

	// get sequence numbers
	MSG_BeginReading();
	sequence = MSG_ReadLong();
	sequence_ack = MSG_ReadLong();

	...

	reliable_message = sequence >> 31;
	reliable_ack = sequence_ack >> 31;
	message_contains_fragments = sequence & (1 << 30) ? true : false;

	COM_UnMunge2(&net_message.data[8], net_message.cursize - 8, sequence & 0xFF);

函数开始定义了一堆sequence, sequence_ack什么的变量，如果学过计算机网络，对此应该都不会陌生，核心意义是为了在udp中模拟tcp实现可靠数据传输，保证一些关键数据包的到达。

虽然函数整体看上去很复杂，但是其实我们主要关注的是代码如何处理输入的数据包数据，所以我们主要关注MSG_ReadLong和MSG_ReadShort这类的函数就可以了。因为只有这类函数才会直接从输入数据中读取信息。

继续阅读Netchan_Process函数，可以知道数据流的前四个字节是seq num，再之后四个字节是seq ack。

Reliable_message和reliable_ack是基于seq和seq_ack生成的标记位，主要与实现可靠传输有关，我们这里可以不太关注。

message_contains_fragments是一个比较关键的变量，他是seq num的第二位，它标记着这段数据有没有被分片。

再之后调用了COM_UnMunge2函数，传递的第一个参数是收到网络数据包第9个字节及以后的内容，第二个参数是这个数据包的大小，第三个参数是序列号的后16位。

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
void COM_UnMunge2(unsigned char *data, int len, int seq)
{
	int i;
	int mungelen;
	int c;
	int *pc;
	unsigned char *p;
	int j;

	mungelen = len & ~3;
	mungelen /= 4;

	for (i = 0; i < mungelen; i++)
	{
		pc = (int *)&data[i * 4];
		c = *pc;
		c ^= seq;

		p = (unsigned char *)&c;
		for (j = 0; j < 4; j++)
		{
			*p++ ^= (0xa5 | (j << j) | j | mungify_table2[(i + j) & 0x0f]);
		}

		c = LongSwap(c);
		c ^= ~seq;
		*pc = c;
	}
}

并不是一段太复杂的代码，甚至我们没必要都读懂，只需要能够大致清楚这段代码是用来对数据做加密的就可以了，似乎是个开发者自己实现的对称加密。而且因为它把代码已经写好了，我们解密的时候直接调用就可以了～

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
	if (message_contains_fragments)
	{
		for (i = 0; i < MAX_STREAMS; i++)
		{
			if (MSG_ReadByte())
			{
				frag_message[i] = true;
				fragid[i] = MSG_ReadLong();
				frag_offset[i] = MSG_ReadShort();
				frag_length[i] = MSG_ReadShort();
			}
		}

		if (!Netchan_Validate(chan, frag_message, fragid, frag_offset, frag_length))
			return FALSE;
	}

	sequence &= ~(1 << 31);
	sequence &= ~(1 << 30);
	sequence_ack &= ~(1 << 31);
	sequence_ack &= ~(1 << 30);

	if (net_showpackets.value != 0.0 && net_showpackets.value != 3.0)
	{
		char c = (chan == &g_pcls.netchan) ? 'c' : 's';

		Con_Printf(
			" %c <-- sz=%i seq=%i ack=%i rel=%i tm=%f\n",
			c,
			net_message.cursize,
			sequence,
			sequence_ack,
			reliable_message,
			(chan == &g_pcls.netchan) ? g_pcl.time : g_psv.time);
	}

	if (sequence <= (unsigned)chan->incoming_sequence)
	{
		if (net_showdrop.value != 0.0) {
			if (sequence == (unsigned)chan->incoming_sequence)
				Con_Printf("%s:duplicate packet %i at %i\n", NET_AdrToString(chan->remote_address), sequence, chan->incoming_sequence);
			else
				Con_Printf("%s:out of order packet %i at %i\n", NET_AdrToString(chan->remote_address), sequence, chan->incoming_sequence);
		}
		return FALSE;
	}

	//
	// dropped packets don't keep the message from being used
	//
	net_drop = sequence - (chan->incoming_sequence + 1);
	if (net_drop > 0 && net_showdrop.value != 0.0)
	{
		Con_Printf("%s:Dropped %i packets at %i\n", NET_AdrToString(chan->remote_address), net_drop, sequence);
	}

	//
	// if the current outgoing reliable message has been acknowledged
	// clear the buffer to make way for the next
	//
	if (reliable_ack == (unsigned)chan->reliable_sequence)
	{
		// Make sure we actually could have ack'd this message
#ifdef REHLDS_FIXES
		if (sequence_ack >= (unsigned)chan->last_reliable_sequence)
#else // REHLDS_FIXES
		if (chan->incoming_acknowledged + 1 >= chan->last_reliable_sequence)
#endif // REHLDS_FIXES
		{
			chan->reliable_length = 0;	// it has been received
		}
	}

	//
	// if this message contains a reliable message, bump incoming_reliable_sequence
	//
	chan->incoming_sequence = sequence;
	chan->incoming_acknowledged = sequence_ack;
	chan->incoming_reliable_acknowledged = reliable_ack;
	if (reliable_message)
	{
		chan->incoming_reliable_sequence ^= 1;
	}

	int statId = chan->flow[FLOW_INCOMING].current & 0x1F;
	chan->flow[FLOW_INCOMING].stats[statId].size = net_message.cursize + UDP_HEADER_SIZE;
	chan->flow[FLOW_INCOMING].stats[statId].time = realtime;
	chan->flow[FLOW_INCOMING].current++;
	Netchan_UpdateFlow(chan);

	if (message_contains_fragments)
	{
		for (i = 0; i < MAX_STREAMS; i++)
		{
			int j;
			fragbuf_t *pbuf;
			int inbufferid;
			int intotalbuffers;

			if (!frag_message[i])
				continue;

			inbufferid = FRAG_GETID(fragid[i]);
			intotalbuffers = FRAG_GETCOUNT(fragid[i]);

			if (fragid[i] != 0)
			{
				pbuf = Netchan_FindBufferById(&chan->incomingbufs[i], fragid[i], true);
				if (pbuf) {
					int len = frag_length[i];
					SZ_Clear(&pbuf->frag_message);
					SZ_Write(&pbuf->frag_message, &net_message.data[msg_readcount + frag_offset[i]], len);
				}
				else {
					Con_Printf("Netchan_Process:  Couldn't allocate or find buffer %i\n", inbufferid);
				}
				// Count # of incoming bufs we've queued? are we done?
				Netchan_CheckForCompletion(chan, i, intotalbuffers);
			}

			// Rearrange incoming data to not have the frag stuff in the middle of it
			int wpos = msg_readcount + frag_offset[i];
			int rpos = wpos + frag_length[i];

			Q_memmove(net_message.data + wpos, net_message.data + rpos, net_message.cursize - rpos);
			net_message.cursize -= frag_length[i];

			for (j = i + 1; j < MAX_STREAMS; j++)
			{
				frag_offset[j] -= frag_length[i]; // fragments order already validated
			}
		}

		// Is there anything left to process?
		if (net_message.cursize <= 16)
			return FALSE;
	}

	return TRUE;
}
image-20211118182351994

看！我们终于看到了服务器传输的明文！也拿到了第三部分flag～

part2: _@@w4d_
part3: h4ppyY*!uNmUng3}
L3HCTF{v41v3#_@@w4d_h4ppy!uNmUng3}

END！🎉

Worked by wchhlbt & idealeer

赏

谢谢你请我吃糖果

扫一扫，分享到微信

微信分享二维码
总访问量: | 总访客:

tag:

    缺失模块。
    1、请确保node版本大于6.2
    2、在博客根目录（注意不是yilia根目录）执行以下命令：
    npm i hexo-generator-json-content --save

    3、在根目录_config.yml里添加配置：

      jsonContent:
    meta: false
    pages: false
    posts:
      title: true
      date: true
      path: true
      text: false
      raw: false
      content: false
      slug: false
      updated: false
      comments: false
      link: false
      permalink: false
      excerpt: false
      categories: false
      tags: true

wchhlbt<br><br>清华大学 网络科学与网络空间研究院<br><br>NISL 实验室<br><br>Email：wchhlbt.me@gmail.com<br><br>欢迎大家！
